9–3 Diagnostic Counters
Publication 1770Ć6.5.16 - October 1996
Cat. Nos. Link Pages
1747ĆKE DH485 9-3
1747ĆL20, ĆL30, ĆL40, ĆL511, ĆL514, ĆL524, ĆL532 À DH485 9-3
1747 L541 L542 L542 Á
DH+ 9-4
1747ĆL541, ĆL542, ĆL542 Á
DH485 9-5
1747ĆL541, ĆL542, ĆL542 Á DF1 9-6
À SLC 500, 5/01, and 5/02 processors
Á SLC 5/03 and 5/04 processors
1747ĆKE DH485 Diagnostic Counters
This counter byte Counts the number of
0
Total message packets received, low byte
1 Total message packets received, high byte
2 Total message packets sent, low byte
3 Total message packets sent, high byte
4 Message packet retries
5 Retry limit exceeded (nonĆdelivery)
6 NAK, no memory sent
7 NAK, no memory received
8 Total bad message packets received
9 Reserved
1747ĆL20, ĆL30, ĆL40, ĆL511, ĆL514, ĆL524, (SLC 500, 5/01, and 5/02
processors), 1747ĆPA2x (SLC APS COM1), 1770ĆKF3, and
1784ĆKR DH485 Diagnostic Counters
This counter byte Counts the number of
0
Total message packets received, low byte
1 Total message packets received, high byte
2 Total message packets sent, low byte
3 Total message packets sent, high byte
4 Message packet retries
5 Retry limit exceeded
6 NAK, no memory sent
7 NAK, no memory received
8 Total bad message packets received
9 Bad messages due to illegal type
1747 Cat. Nos.
