5–6 Data-link Layer Message Frames
Publication 1770Ć6.5.16 - October 1996
CRC Field
For these protocols You calculate the CRC value ➀
fullĆduplex using the value of the linkĆlayer data bytes and the ETX byte.
halfĆduplex
• for master messages using the value of the linkĆlayer data
bytes and the STN, STX and ETX bytes ➁
• for slave messages using the value of the linkĆlayer data bytes
and the ETX byte
➀ The polynomial for a CRC value is: X 16 + X 15 + X 2 + X 0 .
➁ Do not add in the associated DLE for STX and ETX values.
Important: To transmit the data value of 10
16
, you must use the
data symbol DLE DLE. However, only one of these
DLE bytes is included in the CRC value.
Embedded responses are not included in the CRC value.
The following explains the transmission of the CRC value:
1. At the start of a message frame, the transmitter clears a 16-bit
register used for the CRC value.
2. As a byte is transmitted, it is exclusive-ORed (least-significant bit
to the right) with the right eight bits of the CRC register.
3. The result is placed in the right eight bits of the CRC register.
4. The CRC register is then shifted right eight times by inserting 0s
on the left. Each time a 1 is shifted out on the right, the CRC
register is exclusive-ORed with this 16-bit constant:
1010 0000 0000 0001
5. As each additional byte is transmitted, it is included in the value
in the register the same way.
6. After the ETX value is transmitted, the value in the CRC register
is transmitted (right bit first). The receiver also calculates the
CRC value and compares it to the received CRC value to verify
the accuracy of the data received.
