9
Chapter
9–1
Replacement Parts
This chapter provides a list of replacement parts and a list of replacement
terminal blocks for your SLC 500 controller.
This table provides a list of replacement parts and their catalog numbers.
Description Catalog Number
Pre-wired Interface Cable Ċ Available in 1.0m, 2.5m, and 5.0m lengths. 1492-CABLE ➀ H
Replacement Fuses Ċ Five fuses per package. Orders must be for five fuses or multiples of five.
Replacement fuse for Fixed I/O AC units, MDL 1.25 Ampere
1746-F4
Replacement fuse for Fixed I/O DC units, MDL 1.6 Ampere 1746-F5
Modular Card Slot Fillers Ċ Two fillers per package. Orders must be for two fillers or multiples of two. 1746-N2
Connector Ċ Mating Connector for 32 Point user-made cable 1746-N3
Kit consisting of four replacement terminal covers and labels for 4, 8, 16 I/O modules 1746-R9
Replacement Cover for Specialty I/O
Two covers per package. Orders must be for two covers or multiples of two.
1746-R13
Replacement Retainer Clips for Modules
Four clips per package. Orders must be for four clips or multiples of four.
1746-R15
Lithium Battery Assembly
This is an optional part used for the SLC 500 Fixed and Modular Hardware Style processors and the Hand-Held Terminal.
Refer to product documentation for proper storage and handling instructions. For disposal information, consult your nearest
Allen-Bradley Sales Office.
1747-BA
Processor to Peripheral Programming/Communication Cable 1747-C10
Processor to Isolated Link Coupler Cable 1747-C11
Specialty Module to Isolated Link Coupler Cable 1747-C13
EEPROM with 1K User Instructions 1747-M1
UVPROM with 1K User Instructions 1747-M3
Adapter Sockets Ċ Orders must be for five sockets or multiples of five. 1747-M5
Replacement Parts Kit for 20 I/O Fixed Hardware Style Processor
Two Output Terminal Covers
Two Input Terminal Covers
Two Prom/Battery Covers
One HHT/Comm Connector Cover
1747-R5
Replacement Parts Kit for 30 and 40 I/O Fixed Hardware Style Processors
Two Output Terminal Covers
Two Input Terminal Covers
Two Prom/Battery Covers
One HHT/Comm Connector Cover
1747-R7
Replacement Terminal Covers for 4, 8, & 16 I/O Modules
This kit contains four blank covers and appropriate labels for replacement of any required I/O module cover.
1747-R9
HHT Keypad Replacement Overlay for English Memory Pak Firmware Releases 1.02, 1.07 and 1.10 1747-R20
HHT Keypad Replacement Overlay for French Memory Pak Firmware Releases 1.10 1747-R20F
HHT Keypad Replacement Overlay for German Memory Pak Firmware Releases 1.10 1747-R20G
HHT Keypad Replacement Overlay for Italian Memory Pak Firmware Releases 1.10 1747-R20I
HHT Keypad Replacement Overlay for English Memory Pak Firmware Releases 2.00 and Later 1747-R21
HHT Keypad Replacement Overlay for French Memory Pak Firmware Releases 2.00 and Later 1747-R21F
➀ Insert the cable length code into the catalog number. Cable length codes are as follows: 10=1.0m, 25=2.5m, and 50=5.0m. For example, 1492-CABLE25H is a 2.5m cable.
Replacement Parts
