5-12 Communications Data for Modbus
1200 3200 PF Setting H'00000000 (0): None
H'00000001 (1): Run
H'00000002 (2): Stop
H'00000003 (3): RUN/STOP
H'00000004 (4): 100% AT execute
H'00000005 (5): 40% AT execute
H'00000006 (6): Alarm latch cancel
H'00000007 (7): Auto/manual switch
H'00000008 (8): Monitor/setting item Advanced
Setting
Function
Group
1204 3203 Monitor Setting Item 1 H'00000000 (0): Disabled
H'00000001 (1): PV/SP/multi-SP
H'00000002 (2): PV/SP/MV
H'00000003 (3): PV/SP/soak time remain
H'00000004 (4): Proportional band (P)
H'00000005 (5): Integral time (I)
H'00000006 (6): Derivative time (D)
H'00000007 (7): Alarm value 1
H'00000008 (8): Alarm value upper limit 1
H'00000009 (9): Alarm value lower limit 1
H'0000000A (10): Alarm value 2
H'0000000B (11): Alarm value upper limit 2
H'0000000C (12): Alarm value lower limit 2
H'0000000D (13): Alarm value 3
H'0000000E (14): Alarm value upper limit 3
H'0000000F (15): Alarm value lower limit 3 Advanced
Setting
Function
Group
1206 3203 Monitor/Setting Item 2 H’00000000 to H’0000000F (0 to 15)
* Same as for Monitor/Setting Item 1.
1208 3204 Monitor/Setting Item 3 H’00000000 to H’0000000F (0 to 15)
* Same as for Monitor/Setting Item 1.
120A 3205 Monitor/Setting Item 4 H’00000000 to H’0000000F (0 to 15)
* Same as for Monitor/Setting Item 1.
120C 3206 Monitor/Setting Item 5 H’00000000 to H’0000000F (0 to 15)
* Same as for Monitor/Setting Item 1.
130A 3305 Cold Junction Compensation
Method H’00000000 (0): OFF
H’00000001 (1): ON
1314 330A
α
H’00000000…H’00000064 (0.00…1.00)
131E 330F AT Calculated Gain H’00000001…H’00000064 (0.1…10.00)
1320 3310 AT Hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for TC/Pt universal input models)
(0.01 to 9.99 for Analog input models)
1322 3311 Limit Cycle MV Amplitude H'00000032 to H'000001F4 (5.0 to 50.0)
1328 3314 Heater Burnout Latch H’00000000 (0): OFF
H’00000001 (1): ON
132A 3315 Heater Burnout Hysteresis H’00000001…000001F4 (0.1…50.0)
132C 3316 HS Alarm Latch H’00000000 (0): OFF
H’00000001 (1): ON
132E 3317 HS Alarm Hysteresis H’00000001…000001F4 (0.1…50.0)
1334 331A Number of Multi-SP Uses H’00000000 (0): No multi-SP
H’00000001 (1): 2SP
H’00000002 (2): 4SP Initial Setting
function group
Table 5.10
Address Parameter Name Setting (Monitor) Value Function
Group
Four-byte
mode
Two-byte
mode
