Example 3: no node number provided, Example 4: no sub-address, and illegal bcc – Rockwell Automation 900 Temperature Controller Communications Functions - Series B User Manual
Page 20

Publication 900-UM004D-EN-E - July 2010
2-4
Bulletin 900 Communications Procedures 900-TCx (CompoWay/F)
Example 3: No node number provided
Command Format:
The node number is lacking one character.
Response Format:
Example 4: No sub-address, and illegal BCC
Command Format:
Response Format:
Sub-address is 00 and end code is 13 (BCC error).
BCC
ETX
STX
No response
BCC
Err
ETX
STX
Node No.
BCC
ETX
End Code
1
3
Sub-address
0
0
Node No.
STX
