Publication 900-UM004D-EN-E - July 2010

5-8

Communications Data for Modbus

➊ The program end output can be set when the Program Pattern is not set to 0 (OFF).
➋ This cannot be set if the Number of Multi-SP Uses parameter is set to 2.
➌ PRST: Program start can be set when the Program Pattern is not set to 0 (OFF) but the function will be disabled.
➍ P.END (program end output) can be set even when the program pattern is set to OFF, but the

function will be disabled.

➎ The output turns ON when the status of either the Control Output 1 ON/OFF Count Alarm or the

Control Output 2 ON/OFF Count Alarm turns ON.

Table 5.7

Address

Parameter Name

Setting (Monitor) Value

Function

Group

Four-byte

mode

Two-byte

mode

0E0C

2E06

Control Output 1 Assignment

When control output 1 is a linear output:
H'00000000 (0): Not assigned
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
When control output 1 is an ON/OFF output:
H'00000000 (0): Not assigned
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Program end output ➊
H'00000007 (7): Control output ON/OFF count alarm

Advanced
Setting

0E0E

Control Output 2 Assignment

H'00000000 (0): Not assigned
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Program end output ➊
H'00000007 (7): Control output ON/OFF count alarm

0E14

2E0A

Event Input Assignment 1

H'00000000 (0): None
H'00000001 (1): RUN/STOP (Cannot be set if the “Number of
multi-SP uses” is set to 1 or 2.)
H'00000002 (2): Auto/manual switch (Cannot be set if the
“Number of multi-SP uses” is set to 1 or 2.)
H'00000003 (3): Program Start (Cannot be set if the “Number
of multi-SP uses” is set to 1 or 2.)

H'00000004 (4): Direct/reverse operation
H'00000005 (5): None
H'00000006 (6): 100% AT execute/cancel
H'00000007 (7): 40% AT execute/cancel
H'00000008 (8): Setting change enable/disable
H'00000009 (9): Communications writing enable/disable
H'0000000A (10): Alarm latch cancel

0E16

2E0B

Event Input Assignment 2 ➋

H'00000000...H'0000000A (0...10) (Same settings as the Event Input
Assignment 1))

0E20

2E10

Auxiliary Output 1 Assignment

H'00000000 (0): None
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Program end output

H'00000007 (7): Control output ON/OFF count alarm

0E22

2E11

Auxiliary Output 2 Assignment

H'00000000…H'00000007 (0…7) (Same settings as the Auxiliary
Output 1assignments)

0E24

2E12

Auxiliary Output 3 Assignment

H'00000000…H'00000007 (0…7) (Same settings as the Auxiliary
Output 1assignments)
