Rockwell Automation 900 Temperature Controller Communications Functions - Series B User Manual
Page 54

Publication 900-UM004D-EN-E - July 2010
3-12
Communications Data
C3 (83)
0071
Monitor/Setting Item
4
H’00000000...H’0000000F (0 ...5)
* Same as for Monitor/Setting Item 1.
Advanced
function
setting
C3 (83)
0072
Monitor/Setting Item
5
H’00000000...H’0000000F (0 ...5)
* Same as for Monitor/Setting Item 1.
C3 (83)
0073
PV/SP Display Screen
Selection
H’00000000 (0): PV/SP
H’00000001 (1): PV/SP/Multi-SP
PV/SP/MV
H’00000002 (2): PV/SP/MV
PV/SP/Multi-SP
H’00000003 (3): PV/SP/Multi-SP
H’00000004 (4): PV/SP/MV
H’00000005 (5): PV/SP/Multi-SP
PV/SP/Soak Time Remain
H’00000006 (6): PV/SP/MV
PV/SP/Soak Time Remain
H’00000007 (7): PV/SP/Soak Time Remain
C3 (83)
0074
MV Display Screen
Selection
H’00000000 (0): OFF (heating)
H’00000001 (1): ON (cooling)
C3 (83)
0075
PV Decimal Point
Display
H’00000000 (0): OFF
H’00000001 (1): ON
C3 (83)
0076
PV Status Display
Function
H’00000000 (0): OFF
H’00000001 (1): Manual
H’00000002 (2): Stop
H’00000003 (3): Alarm 1
H’00000004 (4): Alarm 2
H’00000005 (5): Alarm 3
H’00000006 (6): Alarm 1 to 3 OR status
H’00000007 (7): Heater alarm
C3 (83)
0077
SV Status Display
Function
H’00000000...H’00000006 (0...7)
* Same as for PV Status Display Function
C3 (83)
0078
Control Output 1
ON/OFF Count Alarm
Set Value
H’00000000...0000270F (0...9999)
C3 (83)
0079
Control Output 2
ON/OFF Count Alarm
Set Value
H’00000000...0000270F (0...9999)
C3 (83)
0083
Display Refresh
Period
H’00000000 (0): OFF
H’00000001 (1): 0.25
H’00000002 (2): 0.5
H’00000003 (3): 1.0
Table 3.3 Variable Type C3 (83)
Variable
Type
Address
Item (Parameter)
Set (Monitor) Value
Function
Group
➊
The input type can be selected to march the connected sensor. There are two input types specifications:
Thermocouple/Resistance thermometer input and Analog input.
➋
The parameter will not be shown on the Controller display when alarm 3 is not assigned to an output.
➌
Communications parameters are enabled after they have been changed by resetting the controller.
➍
For controllers with two event inputs (events 1 and 2), this cannot be set if the number of Multi-SP uses parameter is set to 1
or 2
➎
For controllers with two event inputs (events 1 and 2), this cannot be set if the number of Multi-SP uses parameter is set to 2.
➏
PRST (program start) can be set even when the program pattern is set to OFF, but the function will be disabled.
➐
The logic of CompoWay/F (900-TC) operation command code 00 (communications writing) is not affected.
➑
The setting (monitor) range depends on the transfer output type setting. (See the setting data list for details.)
➒
P.END (program end output) can be set even when the program pattern is set to OFF, but the
function will be disabled.
➓
The output turns ON when the status of either the Control Output 1 ON/OFF Count Alarm or the Control Output 2 ON/OFF
Count Alarm turns ON.
