Response code – Rockwell Automation 900 Temperature Controller Communications Functions - Series B User Manual
Page 30

Publication 900-UM004D-EN-E - July 2010
2-14
Bulletin 900 Communications Procedures 900-TCx (CompoWay/F)
Number of Write Data Items (Variable Type + Write Data)
Response Code
Normal completion
Error occurred
Note: For details on AT (auto-tuning), see publication 900-UM007*.
Table 2.16
Read Data Length
Number of Read Data Items
For double word
12 max.
For word
17 max.
Table 2.17
Response Code
Name
Description
0000
Normal Completion
No errors were found.
Table 2.18
Response Code
Name
Description
1002
Command too short
The command is too short.
1101
Area type error
The variable type is wrong.
1100
Parameter error
• Bit position is not “00”.
• The write data is out of the
setting range.
3003
Read-only error
Variable type “CO” was written
to.
2203
Operation error
• The Communications
Writing parameter is set to
“OFF” (disabled).
• Attempted to write to a
parameter in setup area 1
from setup area 0.
• Attempted to write to a
protect parameter from
other than the protect
group.
• AT (auto-tuning) was in
progress. See note.
• EEPROM error
