Rockwell Automation 900 Temperature Controller Communications Functions - Series B User Manual
Page 92

Publication 900-UM004D-EN-E - July 2010
5-10
Communications Data for Modbus
➊ The parameter will not be shown on the Controller display when Alarm 3 is not assigned to an output.
Table 5.9
Address
Parameter Name
Setting (Monitor) Value
Function
Group
Four-byte
mode
Two-byte
mode
0F0E
2F07
Alarm 3 Latch ➊
H'00000000 (0): OFF
H'00000001 (1): ON
Advanced
Setting
0F10
2F08
Alarm 3 Hysteresis ➊
H'00000001…H'0000270F
(0.1…999.9 for TC/Pt multi-input models)
(0.01…99.99 for Analog input models)
Initial
Setting
0F18
2F0C
Standby Sequence Reset
H'00000000 (0): Condition A
H'00000001 (1): Condition B
Advanced
Setting
0F1A
2F0D
Auxiliary Output 1 Open in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
0F1C
2F0E
Auxiliary Output 2 Open in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
0F1E
2F0F
Auxiliary Output 3 Open in Alarm ➊
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
0F22
2F11
Alarm 1 ON Delay
H'00000000…H'000003E7 (0…999)
0F24
2F12
Alarm 2 ON Delay
H'00000000…H'000003E7 (0…999)
0F26
2F13
Alarm 3 ON Delay ➊
H'00000000…H'000003E7 (0…999)
0F2A
2F15
Alarm 1 OFF Delay
H'00000000…H'000003E7 (0…999)
0F2C
2F16
Alarm 2 OFF Delay
H'00000000…H'000003E7 (0…999)
0F2E
2F17
Alarm 3 OFF Delay ➊
H'00000000…H'000003E7 (0…999)
1000
3000
PV/SP Display Screen Selection
H'00000000 (0): PV/SP
H'00000001 (1): PV/SP/multi-SP
PV/SP/MV
H'00000002 (2): PV/SP/MV
PV/SP/multi-SP
H'00000003 (3): PV/SP/multi-SP
H'00000004 (4): PV/SP/MV
H'00000005 (5): PV/SP/multi-SP
PV/SP/soak time remain
H'00000006 (6): PV/SP/MV
PV/SP/soak time remain
H'00000007 (7): PV/SP/soak time remain
1002
3001
MV Display Selection
H'00000000 (0): MV (heating)
H'00000001 (1): MV (cooling)
1006
3003
Automatic Display Return Time
H'00000000 (0): OFF
H'00000001…00000063 (1…99)
1008
3004
Display Refresh Period
H'00000000 (0):OFF
H'00000001 (1): 0.25
H'00000002 (2): 0.5
H'00000003 (3): 1.0
1010
3008
Additional PV Display
H'00000000 (0): OFF
H'00000001 (1): ON
1016
300B
MV Display
H'00000000 (0): OFF (display of manipulated variable OFF)
H'00000001 (1): ON (display of manipulated variable ON)
1018
300C
Protect Function Group Move time
H'00000001…H'0000001E (1…30)
