Communications Data
3-7
C3 (83)
0016
Event input
assignment 1 ➍
H'00000000 (0): None
H'00000001 (1): RUN/STOP
H'00000002 (2): Auto/manual switch
H'00000003 (3): Program Start ➏
H'00000004 (4): Direct/reverse operation
H'00000005 (5): None
H'00000006 (6): 100% AT execute/cancel
H'00000007 (7): 40% AT execute/cancel
H'00000008 (8): Setting change enable/disable
H'00000009 (9): Communications writing enable/disable
H'0000000A (10): Alarm latch cancel
C3 (83)
0017
Event input
assignment 2 ➎
H’00000000...H’00000000A (0...10)
Same as Event input 1 Assignment
C3 (83)
001A
Multi-SP Uses
H’00000000(0) OFF
H’00000001(1) ON
Advanced
Setting
Function
Group
C3 (83)
001B
SP ramp tim e unit
H’00000000(0) EU/second
H’00000001(1) EU/minute
H’00000002(2) EU/hour
C3 (83)
001C
SP ramp set value
H’00000000(0) OFF
H’00000001…0000270F (1…9999)
Adjust-
ment
C3 (83)
001D
Standby sequence
reset method
H’00000000(0) Condition A
H’00000001(1) Condition B
C3 (83)
001E
Auxiliary output 1
open in alarm
H’00000000(0) Close in alarm
H’00000001(1) Open in alarm
Advanced
Setting
C3 (83)
001F
Alarm 1 hysteresis
H’00000001…0000270F
(0.1…999.9 for TC/Pt multi-input models)
(0.01…99.99 for Analog input models)
Initial
Setting
C3 (83)
0020
Auxiliary output 2
open in alarm
H’00000000(0) Close in alarm
H’00000001(1) Open in alarm
Advanced
Setting
C3 (83)
0021
Alarm 2 hysteresis
H’00000001…0000270F
(0.1…999.9 for TC/Pt multi-input models)
(0.01…99.99 for Analog input models)
Initial
Setting
C3 (83)
0022
Auxiliary output 3
open in alarm➋
H’00000000(0) Close in alarm
H’00000001(1) Open in alarm
Advanced
Function
Setting
C3 (83)
0023
Alarm 3 hysteresis ➋
H’00000001…0000270F
(0.1…999.9 for TC/Pt multi-input models)
(0.01…99.99 for Analog input models)
Initial
Setting
C3 (83)
0024
HB ON/OFF
H’00000000(0) OFF
H’00000001(1) ON
Advanced
Setting
Function
Group
C3 (83)
0025
Heater burnout latch
H’00000000(0) OFF
H’00000001(1) ON
C3 (83)
0026
Heater burnout
hysteresis
H’00000001…00001F4 (0.1…50.0)
C3 (83)
0027
ST stable range
H’00000001…0000270F (0.1…999.9)
C3 (83)
0028
α
H’00000000…H’00000064 (0.00…1 .00)
C3 (83)
0029
MV upper limit
Standard: MV lower limit +0.1…000041A (MV lower limit
+0.1…105.0)
Adjust-
ment
Heating and cooling: H’00000000…H’0000041A (0.0…105.0)
C3 (83)
002A
MV lower limit
Standard: H’FFFFFFCE…MV upper limit -0.1 (-5.0…MV upper
limit -0.1)
Heating and cooling: H’FFFFFBE6…H’00000000 (-105.0…0.0)
Table 3.3 Variable Type C3 (83)
Variable
Type
Address
Item (Parameter)
Set (Monitor) Value
Function
Group
➊
The input type can be selected to march the connected sensor. There are two input types specifications:
Thermocouple/Resistance thermometer input and Analog input.
➋
The parameter will not be shown on the Controller display when alarm 3 is not assigned to an output.
➌
Communications parameters are enabled after they have been changed by resetting the controller.
➍
For controllers with two event inputs (events 1 and 2), this cannot be set if the number of Multi-SP uses parameter is set to 1
or 2
➎
For controllers with two event inputs (events 1 and 2), this cannot be set if the number of Multi-SP uses parameter is set to 2.
➏
PRST (program start) can be set even when the program pattern is set to OFF, but the function will be disabled.
➐
The logic of CompoWay/F (900-TC) operation command code 00 (communications writing) is not affected.
➑
The setting (monitor) range depends on the transfer output type setting. (See the setting data list for details.)
➒
P.END (program end output) can be set even when the program pattern is set to OFF, but the
function will be disabled.
➓
The output turns ON when the status of either the Control Output 1 ON/OFF Count Alarm or the Control Output 2 ON/OFF
Count Alarm turns ON.
