Rockwell Automation Publication 1407-UM001G-EN-P - April 2013
71
Chapter
4
CGCM Unit Configuration
Introduction This section provides a generic set-up and verification procedure for power
generation systems by using the CGCM unit and RSLogix 5000 software. The
various configuration parameters required to customize the device to a specific
application are presented. Because every application is unique, read this section
carefully and make sure that the configuration entries are appropriate for the
system being implemented.
For additional information on RSLogix 5000 software, see Logix5000
Controllers Common Procedures, publication
1756-PM001 .
Overview of the
Configuration Process Follow these steps when you use the RSLogix 5000 software to configure the
CGCM unit.
1. Gather the necessary equipment and information.
2. Create a new module.
3. Enter configuration for the module.
4. Edit configuration for a module when changes are needed.
Preparation Appendix F provides a table for recording configuration settings. It is suggested
that you make a copy of Appendix F , use it to record the setup for each unit, and
retain these records for future reference.
This generator information is needed to configure the CGCM unit:
• Rated frequency
• Rated voltage
• Rated current
• Rated real power
• PMG rated voltage
• Full-load exciter field voltage
• No-load exciter field voltage
• Full-load exciter field current
• Generator direct access transient time constant T’
do
• Generator exciter field time constant T
e
• Number of main and exciter field poles
