136 Rockwell Automation Publication 1407-UM001G-EN-P - April 2013
Chapter 6 CGCM Unit Software Interface
Data Table
Table 10 - Output (scheduled write) Data Table, Assembly Instance 1
Byte Size
in
Bytes Type Bits Tag Name Description Units Range
0 1 Bool 0 RevVARFltOutEn Reverse VAR Fault Output Enable - 0=Disabled,
1=Enabled
Bool 1 RevPwrFltOutEn Reverse Power Fault Output
Enable
Bool 2 OvrExcFltOutEn Over-excitation Fault Output
Enable
Bool 3 Ovr_I_FltOutEn Over-current Fault Output Enable
Bool 4 Undr_V_FltOutEn Under-voltage Fault Output
Enable
Bool 5 Ovr_V_FltOutEn Over-voltage Fault Output Enable
Bool 6 UndrFreqFltOutEn Under-frequency Fault Output
Enable
Bool 7 OvrFreqFltOutEn Over-frequency Fault Output
Enable
1 1 Bool 0 Spare1 - -
Bool 1 LossExcFltOutEn Loss Excitation Fault Output
Enable
0=Disabled,
1=Enabled
Bool 2 OEL_En Over-excitation Limiting Enable
Bool 3 UEL_En Under-excitation Limiting Enable
Bool 4 LossSensingFltOutEn Loss Sensing Fault Output Enable
Bool 5 LossPMGFLtOutEn Loss Permanent Magnet
Generator Fault Output Enable
Bool 6 RotDiodeFltOutEn Rotation Diode Fault Output
Enable
Bool 7 PhRotFltOutEn Phase Rotation Fault Output
Enable
2 1 Bool 0 Spare2 - -
Bool 1 Spare3
Bool 2 EngineIdle Engine Idle 0=False, 1=True
Bool 3 Spare4
Bool 4 PF_VAR_Select Power Factor/VAR Select 0=PF, 1=VAR
Bool 5 PF_VAR_En Power Factor/VAR Enable 0=Disabled,
1=Enabled
Bool 6 AVR_FCR_Select Automatic Voltage
Regulator/Field Current Regulator
Select
0=AVR, 1=FCR
Bool 7 FltReset Fault Reset 0=De-assert,
1=Assert
