132 Rockwell Automation Publication 1407-UM001G-EN-P - April 2013
Chapter 6 CGCM Unit Software Interface
Configuration Checking
No range checking is performed on the Input data table.
Table 7 - Scheduled Read Data Table
Byte Size in
Bytes Type Bits Tag Name Description-+ Units Range
0 4 DINT 0…7 Status_32_bit Connect Status
4 1 Bool 0 RevVARFlt Reverse kVAR Fault - 0=Inactive,
1=Active
Bool 1 RevPwrFlt Reverse kW Fault
Bool 2 OvrExcFlt Over-excitation Fault
Bool 3 Ovr_I_Flt Over-current Fault
Bool 4 Undr_V_Flt Under-voltage Fault
Bool 5 Ovr_V_Flt Over-voltage Fault
Bool 6 UndrFreqFlt Under-frequency Fault
Bool 7 OvrFreqFlt Over-frequency Fault
5 1 Bool 0 CGCM_Flt CGCM Internal Fault - 0=Inactive,
1=Active
Bool 1 LossExcFlt Loss of Excitation Current Fault
Bool 2 OEL_Active Over-excitation Limiting Active
Bool 3 UEL_Active Under-excitation Limiting Active
Bool 4 LossSensingFlt VT Sensing Loss
Bool 5 LossPMGFlt PMG Loss
Bool 6 RotDiodeFlt Rotating Diode Fault
Bool 7 PhRotFlt Phase Rotation Fault
6 1 Bool 0 BusRot_ABC_ACB Rotation Bus - 0=ABC, 1=ACB
Bool 1 GenRot_ABC_ACB Rotation Generator
Bool 2 FltOut Output Active Fault 0=Inactive,
1=Active
Bool 3 ExcOut Excitation Out Enabled 0=Disabled,
1=Enabled
Bool 4 PF_VAR_Selection Power Factor/VAR Selection 0=PF, 1=VAR
Bool 5 PF_VAR_Control_Ened Power Factor/VAR Control Enabled 0=Disabled,
1=Enabled
Bool 6 AVR_FCR_Selection AVR/FCR Control Selection 0=AVR, 1=FCR
Bool 7 FLTResetAck Reset Acknowledge Fault 0=No, 1=Yes
