Rockwell Automation Publication 1407-UM001G-EN-P - April 2013 205
Specifications Appendix D
Over-excitation Limiting - Offline
Under-excitation Limiting
Manual Excitation Control
Metering
Attribute Range Increment
Pickup 0…15 A DC 0.1 A DC
Time delay 0…10 s 1 s
Attribute 1407-CGCM
Real power 0…100% kW for each of 5 points
Reactive power 0…100% kvar for each of 5 points
Attribute 1407-CGCM
Range 0…15.0 A DC
Increment 0.1 A DC
Attribute Range Accuracy
Generator voltage 57…208V AC 0.2% (50/60 Hz)
Generator current 0…5 A AC 0.2% (50/60 Hz)
Generator frequency 10…90 Hz ±0.05 Hz
Bus voltage 57…208V AC < 0.2% (50/60 Hz)
Bus frequency 10…90 Hz ±0.05%
Phase angle ±180° ±1.0°
Field voltage 0…200V DC ±1.25 V or ±1.0% (whichever is
greater)
Field current 0…30 A AC ±0.15 A or ±1.0% (whichever is
greater)
Power factor -0.5…0.5 <0.4% of actual PF
Power - real and reactive 0…200% of nom <0.4% of rated kVA
Load share Resolution: 0.1% of full scale voltage
Load Share entity parameters
LS(+)
LS(-) Ui = 0…5 V
Ci = 101 nF
Ii = 111 µA
Li = 0
