82

Getting started User Manual

In the left pane under "Catalog", click on the marker type you want to use. In the right pane,
select the variant by clicking on it, then click on the Select product button. The marker type
is opened.
Step 3: Add data to the marker

Click with the left mouse button to select the marker you want to add text to.

To move to the next marker, press the Enter key or click on the marker you want to move to.
If you can see a red triangle in a text field after adding text, there is
too much text in the field. Not all of the text is displayed or printed.
You will need to shorten the text or have it automatically adjusted by
the program (see chapter "Adjust font size").
Step 4: Save the file
When you have entered all the text, you can save the file as follows:

On the menu bar, select File > Save.

In the next dialog, enter the file name and click on the Save button.
