User interface
53
The Toolbars
This chapter describes the most important elements of the toolbars.
Many of the standard icons such as saving, formatting, etc. are not described any further.
Standard
The standard toolbar is always visible.
Symbol description
Closing files
Closes the open project. A confirmation prompt concerning the saving might
appear.
Toggle Plot Mode
Switches to plot mode.
Any elements not plottable (e.g. barcode, rectangle) are not shown in the plot
mode.
Toggle Orientation
Switches the view in the workspace between horizontal and vertical view.
Duplicate
Duplicates the selected elements.
Consecutive numbering
Opens the "Consecutive numbering" dialog (see chapter "Consecutive
numbering").
Start/exit Excel editing
The text and barcode field contents can also be edited in Excel (see chapter
"Excel editing").
Toggle between the active layers
Toggle between the project and the marker layer.
The toggle can take place automatically (see chapter "Options view").
