Layout and format, Definitions – Rockwell Automation 1492-PRINT110_PRINT220 ClearTools User Manual User Manual
Page 8

2
Introduction
User Manual
Layout and format
The user manual applies the following conventions:
Bold Important elements in the program like buttons, menu items, toolbars, names,
etc. are printed in bold.
„ “ Names of windows and dialogs and references to other sections are enclosed in
double quotes.
>
This character separates two successive menu items (e.g. View > Zoom)
This symbol means that the actions which follow must be carried out in the
specified order.
Symbols used
Indicates that this is essential information about the program.
Indicates that this is useful additional information.
Definitions
This section explains the special terms that are used in the software.
Marker
Markers are used to identify electrical and electronic elements (terminals, conductors, systems,
devices, etc.) and also to label assets.
Marker type
Marker of a specific type, e.g. Marker Card 1492-Mxxxx
Installation note
In order to install the program you need administrator rights on the computer
involved.
