7. Technical data 42" version (LCN-42, LCS-42)
Barco - LC series - R5976934 - user's manual - Revision 08 - April 2008
________________________________________________________________________________________
7-3
7.6.2 S-Video
4
2
3
1
Item
specification
1,2
Ground
3
Y
4
C
Luminance level
1.0 Vpp
Color level
0.286 Vpp
Connector type
Mini Din 4pin
Termination
75
Ω
Table 7-7
7.6.3 Component Video (mini DIN 8 pin)
1
2
3
4
5
6
7
8
Item
specification
Item
specification
1
GND
5
GND
2
CB
6
CR
3
GND
7
not connected
4
Y
8
not connected
Connector type
Mini Din 8pin
Termination
75
Ω
Table 7-8
