4. Controlling
4-6 ___________________________________________________________Barco - LC series - R5976934 - user's manual - Revision 08 - April 2008
4.3.3 The function keys
Using the function keys, the respective OSD command will immediately be executed.
For information about the commands, please refer to the respective section in the OSD description.
Function key Description refers to
F1 Source selection 5.8.1 Input selection with the function key F1 ,
F2 PIP control setting 5.3.3 PIP control
F3 Switch between master source and PIP source,
the source assigned to input 1 will be assigned
to input 2 and vice versa
F4 In VGA mode: White balance This command has no equivalent in the
OSD: when e.g. a signal looks greenish,
pressing the function key F4 will correct
and adjust the color impression.
F5 Display the monitor address 5.6.1 Set display address
4.3.4 Picture controls with direct access.
Brightness and contrast can be controlled directly via IR RCU. When Brightness or Contrast is pressed, the re-
spective OSD dialog pops up to allow the adjustment.
Please refer to respective section of the OSD description, cf. 5.3.1.1 Brightness , 5.3.1.2 Contrast .
4.3.5 Audio controls with direct access.
Volume, balance, bass and treble can be controlled directly via IR RCU. When the respective keys on the IR re-
mote control unit are pressed,, the respective OSD dialog pops up to allow the adjustment.
Please refer to respective section of the OSD description, cf. 5.5 Audio setting menu
