5. The On Screen Display (OSD)
Barco - LC series - R5976934 - user's manual - Revision 08 - April 2008 ______________________________________________________________________________________ 5-41
5.8 Input Signal Selection
In case multiple sources are connected, the signal for the first input and the second input have to be defined.
To select the signal for the respective input, proceed as follows:
RCU Icon Push button (1: top most)
• Press the ADJ key to activate the OSD • Press 7 to activate the OSD
• Use the left and right cursor keys to navi-
gate to the signal menu (for the first input)
• Press 3 and 4 to navigate to the
signal (for the first menu input)
• Press Enter to select • Press 2 to select
• Use the down cursor keys to open the
input signal selection dialog
• Press 4 to open the input signal
selection dialog
After the source has been selected, its timing is displayed.
In case the timing of the source is not included in the presets of the monitor, the timing of
the monitor which matches best the timing of the source is displayed!
