9. Compliant timing
Barco - LC series - R5976934 - user's manual - Revision 08 - April 2008 ________________________________________________________________________________________ 9-3
9.2 HD-SDI input signals
The HD-SDI input complies with the standard SMPTE 292M.
The HD-SDI input supports the following resolutions (table 2).
Reso
lut
ion
Sample
s
per
tota
l lin
e
To
ta
l l
in
e
s
p
e
r
fr
ame
Sample
s
per
a
ctive
lin
e
Active
lin
e
s
p
e
r
fr
ame
sc
anni
ng
for
m
a
t
fr
ame
rate
[H
z]
1280x720 1650 750 1280 720 1:1 p 60
1280x720 1650 750 1280 720 1:1 p 60/ M
1280x720 1980 750 1280 720 1:1 p 50
1920x1080 2200 1125 1920 1080 2:1 i 30
1920x1080 2200 1125 1920 1080 2:1 i 30/ M
1920x1080 2640 1125 1920 1080 2:1 i 25
1920x1080 2200 1125 1920 1080 1:1 prog 30
1920x1080 2200 1125 1920 1080 1:1 prog 30/ M
1920x1080 2640 1125 1920 1080 1:1 prog 25
1920x1080 2750 1125 1920 1080 1:1 prog 24
HD-SDI-Resolutions (M=1.001, p=progressive, i=interlaced) at data rate 1.485 or 1.485/1.001 Gb/s.
