5. The On Screen Display (OSD)
Barco - LC series - R5976934 - user's manual - Revision 08 - April 2008 ______________________________________________________________________________________ 5-21
Phase
Phase can be adjusted in the range from 0 to 255.
It is recommended to have the monitor warmed up for about 5 minutes before adjusting phase.
Use the Phase adjustment to eliminate shimmering horizontal streaking.
If there are not only horizontal streaking but also vertical banding, start with Clock
adjustment!
RCU Push button (1: top most)
• Use the up and down cursor keys to navigate to
the Phase
• Press 5 and 6 to navigate to Phase
• Use the left and right cursor keys to in-
crease/decrease the value in steps of 1
The current value is indicated.
• Use 3 and 4 to increase/decrease the value in
steps of 1
The current value is indicated.
The value is applied without any further action. Check the test pattern!
Clock
Clock can be adjusted in the range from 0 to 255.
It is recommended to have the monitor warmed up for about 5 minutes before adjusting clock.
Use the Clock adjustment to eliminate broad vertical banding.
RCU Push button (1: top most)
• Use the up and down cursor keys to navigate to
the Clock
• Press 5 and 6 to navigate to Clock
• Use the left and right cursor keys to in-
crease/decrease the value in steps of 1
The current value is indicated.
• Use 3 and 4 to increase/decrease the value in
steps of 1
The current value is indicated.
The value is applied without any further action. Check the test pattern!
