5. The On Screen Display (OSD)
Barco - LC series - R5976934 - user's manual - Revision 08 - April 2008 ______________________________________________________________________________________ 5-29
5.4 OSD setting menu
On the OSD dialog, the position of the OSD can be defined as well as zoom, blend and time out of the OSD.
To activate the OSD menu, proceed as follows:
RCU Icon Push button (1: top most)
• Press the ADJ key to activate the OSD • Press 7 to activate the OSD
• Use the cursor keys to navigate to the OSD
setting menu
• Press 3 and 4 to navigate to the
OSD setting menu
• The icon will turn blue, and the setting
dialog will pop up
• The icon will turn blue, and the set-
ting dialog will pop up
Each time the OSD opens, its position and behavior will be as set on this dialog.
