5. The On Screen Display (OSD)
5-42 __________________________________________________________Barco - LC series - R5976934 - user's manual - Revision 08 - April 2008
The following sources can be connected to the monitor:
Input Interface signals
Video system input VIDEO IN RCA NTSC/PAL
S-VIDEO S-Video Mini Din 4pin NTSC/PAL
YUV (Y Pb/Cb Pr/Cr) Component Mini Din 8 pin NTSC/PAL
RGB input RGB Analog D-Sub 15 pin RGB analog
RGB Digital DVI-D 24 pin RGB digital
HD-SDI input Serial Digital BNC SDI / HDSDI
To select a signal, proceed as follows:
RCU Icon Push button (1: top most)
• Press the ADJ key to activate the OSD • Press 7 to activate the OSD
• Use the left and right cursor keys to navi-
gate to the signal menu
• Press 3 and 4 to navigate to the
signal menu
• Press Enter to select • Press 2 to select
• Use the down cursor keys to open the
input signal selection dialog
• Press 4 to open the input signal
selection dialog
• Use the left and right cursor keys to select
the desired signal
• Press 3 and 4 to select the desired
signal
In case the signal is assigned to input 1, it cannot be assigned to input 2!
To change the signal of input 1 and input 2, input 1 has to be assigned to the signal which
up to then has been assigned to input 2.
In case of two valid signals, input 2 then will automatically be assigned to the signal which
up to then has been assigned to input 1.
In case of more signals, input 2 has to be explicitely assigned to a signal (all but the one
assigned to input 1).
To select HD-SDI input 1 or HD-SDI input 2, first select HD-SDI in the OSD. When it is
highlighted, press 1 to select the signal connected to HD-SDI input 1, or press 2 to select
the signal connected to HD-SDI input 2.
