5. The On Screen Display (OSD)
Barco - LC series - R5976934 - user's manual - Revision 08 - April 2008 ________________________________________________________________________________________ 5-7
5.3.1 Display
On the Display dialog, brightness and contrast as well as hue, saturation, flesh tone can be adjusted (for VGA
sources only: also black level adjustment)
To activate the Display dialog, proceed as follows:
RCU Icon Push button (1: top most)
• Press the ADJ key to activate the OSD • Press 7 to activate the OSD
• Use the left and right cursor keys to navi-
gate to the signal menu
• Press 3 and 4 to navigate to the
signal menu
• Press Enter to select • Press 2 to select
• Use the left and right cursor keys to navi-
gate to Display
• Press 3 and 4 to navigate to Display
• Press Enter to select – or –
• Press the down key to activate the dialog • Press 2 to select – or –
• Press 5 to activate the dialog
