12. Accessories

12-8 __________________________________________________________Barco - LC series - R5976934 - user's manual - Revision 08 - April 2008

12.4 Fixed wall mount

First mount the screen bracket to the monitor, cf.

. Screen bracket (adapter plate)

Use the fixed wall mount to attach the monitor to the wall.

The drawings show the fixation facility itself and a monitor which is equipped with a fixed wall mount.

12.4.1 Scope of delivery

The fixed wall mount comes in one piece. The 4 screws to attach it to the wall have to be provided on site!
