5. The On Screen Display (OSD)
Barco - LC series - R5976934 - user's manual - Revision 08 - April 2008 ______________________________________________________________________________________ 5-33
5.5.1 Volume
Volume can be adjusted in the range from 0 to 79.
Use the push button 3 on the right rear side of the monitor to directly increase the volume,
use the push button 4 to directly decrease the volume.
RCU Push button (1: top most)
• Use the up and down cursor keys to navigate to
the Volume
• Press 5 and 6 to navigate to Volume
• Use the left and right cursor keys to in-
crease/decrease the value in steps of 1
The current value is indicated.
• Use 3 and 4 to increase/decrease the value in
steps of 1
The current value is indicated.
The value is applied without any further action.
5.5.2 Balance
Balance can be adjusted in the range from -15 to +15.
The zero position is in the center of the slider. In case the left and the right speaker are not balanced, i.e. one
side is predominant, adjust the setting in negative direction to bring out the left speaker, in positive direction to
bring out the right speaker.
RCU Push button (1: top most)
• Use the up and down cursor keys to navigate to
the Balance
• Press 5 and 6 to navigate to Balance
• Use the left and right cursor keys to in-
crease/decrease the value in steps of 1
The current value is indicated.
• Use 3 and 4 to increase/decrease the value in
steps of 1
The current value is indicated.
The value is applied without any further action.
5.5.3 Bass
Bass can be adjusted in the range from -7 to +7.
The zero position is in the center of the slider. In case the low frequencies are predominant, adjust the slider to
the left. In case they are rather faint or missing, adjust the slider to the right,
Th iti i i th t f th lid I
RCU Push button (1: top most)
• Use the up and down cursor keys to navigate to
the Bass
• Press 5 and 6 to navigate to Bass
• Use the left and right cursor keys to in-
crease/decrease the value in steps of 1
The current value is indicated.
• Use 3 and 4 to increase/decrease the value in
steps of 1
The current value is indicated.
The value is applied without any further action.
