Text mode
Original mode

5. The On Screen Display (OSD)

Barco - LC series - R5976934 - user's manual - Revision 08 - April 2008

________________________________________________________________________________________

5-5

To activate a menu, proceed as follows:

RCU

Icon

Push button (1: top most)

• Use the left and right cursor key to select a

• Use the push buttons 3, 4 to select a

• Menus without a submenu will turn blue

and display their settings dialog

• Menus with a sub menu will turn blue and

require an additional key stroke to open the
settings dialog:
Use Enter to open the signal setting sub-
menu
Use the down cursor key to open the signal
selection dialog

• Menus without a submenu will turn

blue and display their settings dialog

• Menus with a sub menu will turn

blue and require an additional key
stroke to open the settings dialog:
Use 2 to open the signal setting sub-
menu
Use 5 to open the signal selection
dialog
