Rockwell Automation Publication 193-UM012B-EN-P - June 2011 91
Appendix B
Overload Object — CLASS CODE 0x2C
No class attributes are supported for the Overload Object. A single instance
(instance 1) of the Overload Object is supported:
The following common services are implemented for the Overload Object:
PCP Object — CLASS CODE 0xC2
The following class attributes are supported for the PCP Object:
Table 39 - Overload Object Instance Attributes
Attribute ID Access Rule Name Data Type Value
7 Get % Thermal Utilized USINT xxx% FLA
108 Get Average % FLA UINT 0…1000%FLA
109 Get % Thermal Utilized USINT 0…100%
127 Get/Set Single/Three Phase BOOL 0=Single Phase
1=Three Phase
132 Get/Set OL Warn Level USINT 0…100% TCU
141 Get/Set Jam Inhibit Time USINT 0…250 s
142 Get/Set Jam Trip Delay USINT 0.5…25.0 s
143 Get/Set Jam Trip Level UINT 150…600%FLA
144 Get/Set Jam Warn Level UINT 100…600%FLA
145 Get/Set UL Inhibit Time USINT 0…250 s
148 Get/Set UL Warn Level USINT 30…100%FLA
Table 40 - Overload Object Common Services
Service
Code Implemented for: Service Name
Class Instance
0x0E No Yes Get Attribute Single
0x10 No Yes Set Attribute Single
Table B.1 PCP Object Class Attributes
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
