Chapter 6
OutA En FltValue
Parameter No.
37
This parameter determines the state that Output A
assumes when a EtherNet/IP network fault occurs
and the FltState is set to “0”.
0 = Open
1 = Closed
Access Rule
Get/Set
Data Type
BOOL
Units
—
Min. Value
0
Max. Value
1
Default Value
0
Tag Name
OutA_En_FLTValue
OutA En IdlState
Parameter No.
38
This parameter, in conjunction with the IdlState,
defines how Output A will respond when the
EtherNet/IP network is idle (clear mode). When
set to “1”, Output A will hold the state prior to trip
occurrence. When set to “0”, Output A will open
or close. The En Flt parameters supersede the En
Idl parameters.
0 = Go to IdlValue
1 = Hold Last State
Access Rule
Get/Set
Data Type
BOOL
Units
—
Min. Value
0
Max. Value
1
Default Value
0
Tag Name
OutA_En_IdlState
OutA En IdlValue
Parameter No.
39
This parameter determines the state that Output A
assumes when the network is idle and instructed
by the IdlState parameter.
0 = Open
1 = Closed
Access Rule
Get/Set
Data Type
BOOL
Units
—
Min. Value
0
Max. Value
1
Default Value
0
Tag Name
OutA_En_IdlValue
IN1 Assignment
Parameter No.
40
This parameter allows the user to assign a
specific function to the discrete IN1 input.
0 = Normal
1 = Trip Reset
2 = OL Contact
Access Rule
Get/Set
Data Type
USINT
Units
—
Min. Value
0
Max. Value
2
Default Value
0
Tag Name
IN1_Assignment
