Rockwell Automation Publication 193-UM012B-EN-P - June 2011 83
Appendix B
Assembly Object — CLASS CODE 0x04
The following class attributes are supported for the Assembly Object:
Instance Attributes
Instances/Connection points implements the following data attributes:
Output Assemblies
The following output assembly instances are implemented:
Table 13 - Assembly Object Class Attributes
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 0x0002
2 Get Max Instance UINT 120
Table 14 - Instance Attributes
# Access Name Type Value Description
1 Get Number of members in
list UINT N/A No. of members to follow in the list in attribute #2
2 Get Member list Array of N/A Array of CIP paths
3 Get/Set Data Array of UINT — Data produced/consumed by the module
4 Get Size UINT N/A No. of USINTs in attribute #3
100 Get Name SHORT_STRING N/A Name of the assembly instance
Table 15 - Instance 2 — Basic Overload Output Assembly from ODVA Profile
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Trip Reset
Table 16 - Instance 101 — Similar to Basic Contact Output Assembly from ODVA
Contact Profile
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Output A
Table 17 - Instance 103 — Similar to Basic Starter Output Assembly from ODVA
Starter Profile
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Trip Reset Output A
