Appendix B
Input Assemblies
Table 18 - Instance 50 — Trip Status Input Assembly from ODVA Overload Profile
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Tripped
Table 19 - Instance 51 —Basic Status Input Assembly from ODVA Overload Profile
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Warning
Tripped
Table 20 - Instance 106 —Motor Starter Input Assembly
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Motor
Current
Input 2
Input 1
Out A Stat Warning
Tripped
Table 21 - Instance 110 —Extended Motor Starter Input Assembly
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Motor
Current
Input 2
Input 1
Out A Stat Warning
Tripped
1
Unused
2
Average % FLA (low byte)
3
Average % FLA (high byte)
4
%Therm Utilized (low byte)
5
%Therm Utilized (high byte)
Table 22 - Instance 111 —Complete Motor Starter Input Assembly
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Motor
Current
Input 2
Input 1
Out A Stat Warning
Tripped
1
Unused
2
Average % FLA (low byte)
3
Average % FLA (high byte)
4
%Therm Utilized (low byte)
5
%Therm Utilized (high byte)
6
Trip Status (low byte)
7
Trip Status (high byte)
8
Warning Status (low byte)
9
Warning Status (high byte)
10
Device Status (low byte)
11
Device Status (high byte)
12
Trip Log 0 (low byte)
13
Trip Log 0 (high byte)
14
Trip Log 1 (low byte)
15
Trip Log 1 (high byte)
