The following instance attributes are supported for all parameter group instances:
The following common services are implemented for the Parameter Group
Object:
Control Supervisor Object — CLASS CODE 0x29
No class attributes are supported for the Control Supervisor Object. A single
instance (instance 1) of the Control Supervisor Object is supported. The
following instance attributes are supported.
Table 35 - Parameter Group Object Instance Attributes
Attribute ID Access Rule Name Data Type Value
1 Get Group Name String SHORT_STRING N/A
2 Get Number of Members UINT N/A
3 Get 1st Parameter UINT N/A
4 Get 2nd parameter UINT N/A
n Get Nth Parameter UINT N/A
Table 36 - Parameter Group Object Common Services
Service
Code Implemented for: Service Name
Class Instance
0x0E Yes Yes Get Attribute Single
Table 37 - Control Supervisor Object Instance 1 Attributes
Attribute ID Access Rule Name Data Type Value
10 Get Faulted BOOL 0=No Fault present
1= Fault Latched
11 Get Warning BOOL 0=No Warnings present
1=Warning present (not latched)
12 Get/Set Fault Rst BOOL 0=No action
0->1=Fault reset
13 Get FaultCode UINT If in Faulted state, FaultCode indicates the fault that caused the transition to
Faulted state. If not in Faulted state, FaultCode indicates the fault that
caused the last transition to the Faulted state.
14 Get Warning Code UINT Code word indicating warning present. If multiple warnings are present, the
lowest code value is displayed.
100 Get Trip Status WORD Bit 0=Overload
Bit 1=Phase Loss
Bit 2=Jam
Bit 3-Bit 15=Not used
