4
Rockwell Automation Publication 20A-IN009D-EN-P - June 2013
PowerFlex 70 Adjustable Frequency AC Drive
Catalog Number Explanation
Refer to the table below for a description of the catalog numbers.
See
Catalog Number Explanation (continued) on page 5
Position Number
1-3
4
5-7
8
9
10
11
12
13
14
15
16
20A
B
2P2
A
3
A
Y
Y
N
N
C
0
a
b
c
d
e
f
g
h
i
j
k
l
a
Drive
Code
Type
20A
PowerFlex 70
b
Voltage Rating
Code
Voltage
Ph.
B
240V AC
3
C
400V AC
3
D
480V AC
3
E
600V AC
3
c1
ND Rating
208V, 60 Hz Input
Code
Amps
kW (Hp)
Frame
2P2
2.5
0.37 (0.5)
A
4P2
4.8
0.75 (1.0)
A
6P8
7.8
1.5 (2.0)
B
9P6
11
2.2 (3.0)
B
015
17.5
4.0 (5.0)
C
022
25.3
5.5 (7.5)
D
028
32.2
7.5 (10)
D
042
43
11 (15)
D
054
62.1
15 (20)
E
070
78.2
18.5 (25)
E
c2
ND Rating
240V, 60 Hz Input
Code
Amps
kW (Hp)
Frame
2P2
2.2
0.37 (0.5)
A
4P2
4.2
0.75 (1.0)
A
6P8
6.8
1.5 (2.0)
B
9P6
9.6
2.2 (3.0)
B
015
15.3
4.0 (5.0)
C
022
22
5.5 (7.5)
D
028
28
7.5 (10)
D
042
42
11 (15)
D
054
54
15 (20)
E
070
70
18.5 (25)
E
c3
ND Rating
400V, 50 Hz Input
Code
Amps
kW (Hp)
Frame
1P3
1.3
0.37 (0.5)
A
2P1
2.1
0.75 (1.0)
A
3P5
3.5
1.5 (2.0)
A
5P0
5.0
2.2 (3.0)
B
8P7
8.7
4.0 (5.0)
B
011
11.5
5.5 (7.5)
C
015
15.4
7.5 (10)
C
022
22
11 (15)
D
030
30
15 (20)
D
037
37
18.5 (25)
D
043
43
22 (30)
D
060
60
30 (40)
E
072
72
37 (50)
E
c4
ND Rating
480V, 60 Hz Input
Code
Amps
kW (Hp)
Frame
1P1
1.1
0.37 (0.5)
A
2P1
2.1
0.75 (1.0)
A
3P4
3.4
1.5 (2.0)
A
5P0
5.0
2.2 (3.0)
B
8P0
8.0
3.7 (5.0)
B
011
11
5.5 (7.5)
C
014
14
7.5 (10)
C
022
22
11 (15)
D
027
27
15 (20)
D
034
34
18.5 (25)
D
040
40
22 (30)
D
052
52
30 (40)
E
065
65
37 (50)
E
c5
ND Rating
600V, 60 Hz Input
Code
Amps
kW (Hp)
Frame
0P9
0.9
0.37 (0.5)
A
1P7
1.7
0.75 (1.0)
A
2P7
2.7
1.5 (2.0)
A
3P9
3.9
2.2 (3.0)
B
6P1
6.1
4.0 (5.0)
B
9P0
9.0
5.5 (7.5)
C
011
11
7.5 (10)
C
017
17
11 (15)
D
022
22
15 (20)
D
027
27
18.5 (25)
D
032
32
22 (30)
D
041
41
30 (40)
E
052
52
37 (50)
E
CE certification testing has not been
performed on 600V class drives.
d
Enclosure
Code
Enclosure
A
Panel Mount - IP 20, NEMA/UL
Type 1
C
Wall/Machine Mount = IP66,
NEMA/UL Type 4X/12 for
indoor use only
F
Flange Mount - Front Chassis =
IP 20, NEMA/UL Type 1; Rear
Heatsink = IP66, NEMA/UL
Type 4X/12 for indoor/outdoor
use
G
Wall/Machine Mount - IP54,
NEMA/UL Type 12
Only available on Frame E.
e
HIM
Code
Interface Module
0
Blank Cover
3
Full Numeric LCD
5
Prog. Only LCD
Only available with NEMA 4X, option C.
