Rockwell Automation 20A PowerFlex 70 Adjustable Frequency AC Drive User Manual
Page 34
34
Rockwell Automation Publication 20A-IN009D-EN-P - June 2013
PowerFlex 70 Adjustable Frequency AC Drive
E
B
D
E
JP1/JP2
Installed
JP3/JP4
Not installed
Solid ground
Install jumpers at both locations (JP1/JP2 and JP3/JP4).
Non-solid ground
Remove the jumper at “JP1/JP2.” Verify that the jumper
at “JP3/JP4” is also removed.
C
JP1/JP2
Installed
JP3/JP4
Installed
Fram
e
Vo
lt
ag
e
Co
de
Factory Default Jumper Settings
Power Source Type
MOV/Input Filter Caps
DC Bus Common Mode
Caps
JP1
JP2
JP4
JP3
MOV /
Filter Cap
CM Cap
