Rockwell Automation 20A PowerFlex 70 Adjustable Frequency AC Drive User Manual
Page 33
Rockwell Automation Publication 20A-IN009D-EN-P - June 2013
33
PowerFlex 70 Adjustable Frequency AC Drive
C
B
D
E
JP2/JP3
Installed
JP3A/JP3B
Not installed
Solid ground
Install jumpers at both locations
(JP2/JP3 and JP3A/JP3B).
Non-solid ground
Remove the jumper at “JP2/JP3.” Verify that the jumper
at “JP3A/JP3B” is also removed.
C
JP2/JP3
Installed
JP3A/JP3B
Installed
D
B
D
E
JP2/JP3
Installed
JP3A/JP3B
Not installed
Solid ground
Install jumpers at both locations
(JP2/JP3 and JP3A/JP3B).
Non-solid ground
Remove the jumper at “JP2/JP3.” Verify that the jumper
at “JP3A/JP3B” is also removed.
C
JP2/JP3
Installed
JP3A/JP3B
Installed
Fram
e
Vo
lt
ag
e
Co
de
Factory Default Jumper Settings
Power Source Type
MOV/Input Filter Caps
DC Bus Common Mode
Caps
JP3 JP2
JP3A
JP3B
MOV / Filter Cap
CM Cap
JP3
JP2
JP3A
JP3B
MOV / Filter Cap
CM Cap
SHLD
