PowerFlex 70 Adjustable Frequency AC Drive
Table 8 - 208/240 Volt AC Three-phase Input Drive Ratings and Input Protection Devices
Cat.No.
Fr
am
e
Hp
Rating
Input
Ratings
Output Amps
Dual
Element Time
Delay Fuse
Non-time
Delay Fuse
Circuit
Breaker
Motor
Circuit
Protector
140M Motor Protector with Adjustable Current Range
ND
HD
Amps kVA Cont. 1 Min. 3 Sec.
Min
Max
Min
Max
Max
Available Catalog Numbers
Minimum
Enclosure Volume
(in.
3
)
208 Volt AC Input
20AB2P2
A 0.5
0.33 2.9
1.1
2.5
2.7
3.7
6
6
6
10
15
7
140M-C2E-B40 140M-D8E-B40 –
3441
20AB4P2
A 1
0.75 5.6
2
4.8
5.5
7.4
10
10
10
17.5
15
7
140M-C2E-B63 140M-D8E-B63 –
3441
20AB6P8
B 2
1.5
10
3.6
7.8
10.3
13.8
15
15
15
30
30
15
140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 3441
20AB9P6
B 3
2
14
5.1
11
12.1
16.5
20
25
20
40
40
30
140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AB015
C 5
3
16
5.8
17.5
19.2
26.6
20
35
20
70
70
30
140M-C2E-C20 140M-D8E-C20 140M-F8E-C20 3441
20AB022
D 7.5
5
23.3
8.3
25.3
27.8
37.9
30
50
30
100
100
30
–
140M-D8E-C25 140M-F8E-C25 5098
20AB028
D 10
7.5
29.8
10.7 32.2
37.9
50.6
40
70
40
125
125
50
–
–
140M-F8E-C32 5098
20AB042
D 15
10
39.8
14.3 43
55.5
74
60
100
60
175
175
70
–
–
140M-F8E-C45 5098
20AB054
E 20
15
57.5
20.7 62.1
72.4
96.6
80
125
80
200
200
100
–
–
–
–
20AB070
E 25
20
72.3
26.0 78.2
93.1
124
90
175
90
300
300
100
–
–
–
–
240 Volt AC Input
20AB2P2
A 0.5
0.33 2.5
1.1
2.2
2.4
3.3
3
4.5
3
8
15
3
140M-C2E-B25 140M-D8E-B25 –
3441
20AB4P2
A 1
0.75 4.8
2
4.2
4.8
6.4
6
9
6
15
15
7
140M-C2E-B63 140M-D8E-B63 –
3441
20AB6P8
B 2
1.5
8.7
3.6
6.8
9
12
15
15
15
25
25
15
140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 3441
20AB9P6
B 3
2
12.2
5.1
9.6
10.6
14.4
20
20
20
35
35
15
140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AB015
C 5
3
13.9
5.8
15.3
17.4
23.2
20
30
20
60
60
30
140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AB022
D 7.5
5
19.9
8.3
22
24.4
33
25
45
25
80
80
30
–
140M-D8E-C25 140M-F8E-C25 5098
20AB028
D 10
7.5
25.7
10.7 28
33
44
35
60
35
110
110
50
–
–
140M-F8E-C32 5098
20AB042
D 15
10
38.7
16.1 42
46.2
63
50
90
50
150
150
50
–
–
140M-F8E-C45 5098
20AB054
E 20
15
49.8
20.7 54
63
84
60
100
60
200
200
100
–
–
–
–
20AB070
E 25
20
64.5
26.8 70
81
108
90
150
90
275
275
100
–
–
–
–
See
Table 9 - 400/480 Volt AC Three-phase Input Drive Ratings and Input Protection Devices
Cat.No.
Fr
am
e
Hp
Rating
Input
Ratings
Output Amps
Dual
Element Time
Delay Fuse
Non-time
Delay Fuse
Circuit
Breaker
Motor
Circuit
Protector
140M Motor Protector with Adjustable Current Range
ND
HD
Amps kVA Cont. 1 Min. 3 Sec.
Min
Max
Min
Max
Max
Max
Available Catalog Numbers
Minimum
Enclosure Volume
(in.
3
400 Volt AC Input
20AC1P3 A 0.37 0.25 1.6
1.1
1.3
1.4
1.9
3
3
3
5
15
3
140M-C2E-B16 –
–
3441
20AC2P1 A 0.75 0.55 2.5
1.8
2.1
2.4
3.2
4
6
4
8
15
7
140M-C2E-B25 140M-D8E-B25 –
3441
20AC3P5 A 1.5
1.1
4.3
3
3.5
4.5
6
6
6
6
12
15
7
140M-C2E-B63 140M-D8E-B63 –
3441
20AC5P0 B 2.2
1.5
6.5
4.5
5
5.5
7.5
10
10
10
20
20
15
140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 3441
20AC8P7 B 4
3
11.3
7.8
8.7
9.9
13.2
15
17.5
15
30
30
15
140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AC011 C 5.5
4
10.5
7.6
11.5
13
17.4
15
25
15
45
40
15
140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AC015 C 7.5
5.5
15.1
10.4 15.4
17.2
23.1
20
30
20
60
60
20
140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AC022 D 11
7.5
21.9
15.2 22
24.2
33
30
45
30
80
80
30
–
140M-D8E-C25 140M-F8E-C25 5098
20AC030 D 15
11
30.3
21
30
33
45
40
60
40
120
120
50
–
–
140M-F8E-C32 5098
20AC037 D 18.5 15
35
24.3 37
45
60
50
80
50
125
140
50
–
–
140M-F8E-C45 5098
20AC043 D 22
18.5 40.7
28.2 43
56
74
60
90
60
150
160
70
–
–
–
–
20AC060 E 30
22
56.8
39.3 60
66
90
80
125
80
225
240
80
–
–
–
–
20AC072 E 37
30
68.9
47.8 72
90
120
90
150
90
250
280
100
–
–
–
–
480 Volt AC Input
20AD1P1 A 0.5
0.33 1.3
1.1
1.1
1.2
1.6
3
3
3
4
15
3
140M-C2E-B16 –
–
3441
20AD2P1 A 1
0.75 2.4
2
2.1
2.4
3.2
3
6
3
8
15
3
140M-C2E-B25 140M-D8E-B25 –
3441
20AD3P4 A 2
1.5
3.8
3.2
3.4
4.5
6
6
6
6
12
15
7
140M-C2E-B40 140M-D8E-B40 –
3441
20AD5P0 B 3
2
5.6
4.7
5
5.5
7.5
10
10
10
20
20
15
140M-C2E-B63 140M-D8E-B63 –
3441
20AD8P0 B 5
3
9.8
8.4
8
8.8
12
15
15
15
30
30
15
140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 3441
20AD011 C 7.5
5
9.4
7.9
11
12.1
16.5
15
20
15
40
40
15
140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AD014 C 10
7.5
12.4
10.4 14
16.5
22
20
30
20
50
50
20
140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
