Programming and Parameters 3-7
Motor Control File
Fil
e
Gr
oup
No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values Related
MO
T
O
R C
O
NTR
O
L
Motor D
ata
040 [Motor Type]
Set to match the type of motor connected.
(1)
Important: Selecting option 1 or 2 also requires selection of “Custom
V/Hz,” option 2 in parameter 53.
Default:
Options:
0
0
1
2
“Induction”
“Induction”
“Synchr Reluc”
(1)
“Synchr PM”
(1)
053
041 [Motor NP Volts]
Set to the motor nameplate rated volts.
Default:
Min/Max:
Units:
Based on Drive Rating
0.0/[Rated Volts]
0.1 VAC
042 [Motor NP FLA]
Set to the motor nameplate rated full load amps.
Default:
Min/Max:
Units:
Based on Drive Rating
0.0/[Rated Amps] × 2
0.1 Amps
047 , 048
043 [Motor NP Hertz]
Set to the motor nameplate rated frequency.
Default:
Min/Max:
Units:
Based on Drive Cat. No.
5.0/400.0 Hz
0.1 Hz
044 [Motor NP RPM]
Set to the motor nameplate rated RPM.
Default:
Min/Max:
Units:
1750 RPM
60/2400 RPM
1 RPM
045 [Motor NP Power]
Set to the motor nameplate rated power.
Default:
Min/Max:
Units:
Based on Drive Rating
0.00/100.00
0.01 kW/HP
See
[Mtr NP Pwr Units]
046
046 [Mtr NP Pwr Units]
Selects the motor power units to be used.
Default:
Options:
0
1
Drive Rating Based
“Horsepower”
“kiloWatts”
047 [Motor OL Hertz]
Selects the output frequency below which the motor operating current is
derated. The motor thermal overload will generate a fault at lower levels
of current.
Default:
Min/Max:
Units:
Motor NP Hz/3
0.0/Motor NP Hz
0.1 Hz
042 , 220
048 [Motor OL Factor]
Sets the operating level for the motor overload.
Default:
Min/Max:
Units:
1.00
0.20/2.00
0.01
042 , 220
To
rq
Attrib
utes
053 [Torque Perf Mode]
Sets the method of motor torque production.
Default:
Options:
0
0
1
2
3
“Sensrls Vect”
“Sensrls Vect”
“SV Economize”
“Custom V/Hz”
“Fan/Pmp V/Hz”
054 [Maximum Voltage]
Sets the highest voltage the drive will output.
Default:
Min/Max:
Units:
Drive Rated Volts
Rated Volts x 0.25/Rated Volts
0.1 VAC
055 [Maximum Freq]
Sets the highest frequency the drive will output. Refer to parameter 083
[Overspeed Limit].
Default:
Min/Max:
Units:
110.0 or 130.0 Hz
5.0/420.0 Hz
0.1 Hz
083
056 [Compensation]
Enables/disables correction options.
32
Motor FLA x OL Factor = Operating Level
1 0 x x x x x x x x x x x x x
10 1 2 3 4 5 6 7 8 9 11 12 13 14 15
1 =Enabled
0 =Disabled
x =Reserved
Bit #
Factory Default Bit Values
Enab
le Jerk
Ixo A
utoCalc
Reflected W
ave
0
0
