3-10 Programming and Parameters
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Basic Program Group (continued)
P107 [Stop Mode] Related Parameter(s): P106 , A418 , A425 , A427 , C304
Active stop mode for all stop sources [e.g. keypad, run forward (I/O Terminal 02), run reverse (I/O
Terminal 03), RS485 port] except as noted below.
Important: I/O Terminal 01 is always a coast to stop input except when
P106 [Start Source] is set for
“3-Wire” control. When in three wire control, I/O Terminal 01 is controlled by P107 [Stop Mode].
Options 0 “Ramp, CF” (1) (Default) Ramp to Stop. “Stop” command clears active fault.
1 “Coast, CF” (1) Coast to Stop. “Stop” command clears active fault.
2 “DC Brake, CF”
(1)
DC Injection Braking Stop. “Stop” command clears active
fault.
3 “DCBrkAuto,CF” (1) DC Injection Braking Stop with Auto Shutoff.
•
Standard DC Injection Braking for value set in A424 [DC
Brake Time].
OR
• Drive shuts off if the drive detects that the motor is
stopped.
“Stop” command clears active fault.
4 “Ramp” Ramp to Stop.
5 “Coast” Coast to Stop.
6 “DC Brake” DC Injection Braking Stop.
7 “DC BrakeAuto” DC Injection Braking Stop with Auto Shutoff.
•
Standard DC Injection Braking for value set in A424 [DC
Brake Time].
OR
• Drive shuts off if current limit is exceeded.
(1) Stop input also clears active fault.
