P-4 Overview
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Catalog Number Explanation
Code Voltage Ph.
V 120V AC 1
A 240V AC 1
B 240V AC 3
D 480V AC 3
Code Version
3
No Brake IGBT
4 Standard
Code Interface Module
1
Fixed Keypad
Code Enclosure
N
Panel Mount - IP 20 (NEMA Type Open)
1-3 4 5 6-8 9 10 11 12 13-14
22F - D 8P7 N 1 1 3 AA
Drive Dash Voltage Rating Rating Enclosure HIM Emission Class Type Optional
Code
22F
PowerFlex 4M
Code Purpose
AA
Reserved for
thru custom firmware
ZZ
Output Current @ 380-480V Input
Code Amps kW (HP)
1P5 1.5 0.4 (0.5)
2P5 2.5 0.75 (1.0)
4P2 4.2 1.5 (2.0)
6P0 6.0 2.2 (3.0)
8P7 8.7 3.7 (5.0)
013 13.0 5.5 (7.5)
018 18.0 7.5 (10.0)
024 24.0 10.0 (15.0)
Output Current @ 100-120V Input
Code Amps kW (HP)
1P6 1.6 0.2 (0.25)
2P5 2.5 0.4 (0.5)
4P5 4.5 0.75 (1.0)
6P0 6.0 1.1 (1.5)
Output Current @ 200-240V Input
Code Amps kW (HP)
1P6 1.6 0.2 (0.25)
2P5 2.5 0.4 (0.5)
4P2 4.2 0.75 (1.0)
8P0 8.0 1.5 (2.0)
011 11.0 2.2 (3.0)
012 12.0 2.2 (3.0)
017 17.5 3.7 (5.0)
025 25.0 5.5 (7.5)
033 33.0 7.5 (10.0)
Code Rating
0
Not Filtered
1 Filtered
Additional accessories, options and adapters are available. See Appendix B for details.
