40
Operation Method
External Output Terminal (optional)
Specification
Temperature Output
(ANALOG)
• The current (mA) corresponding to the measured temperature is output.
• Output temperature range: 0 to 160℃
• Output current: 4 to 20ｍA
• Load: 600Ω or bellow
• Resolution: ±2℃ (±0.2mA)
• Connection: M4 screw terminal block
Time-up Output
(TIME UP)
• It is output when operation is completed, including an abortion.
• a-contact (relay contact)
• Contact capacity: 250V AC, 1A (resistance load)
• Connection: M4 screw terminal block
Alarm Output
(ALARM)
• It is output when an abnormality is detected. Refer to "Safety Device and
Error Code" in Page 45. It is not, however, output when an abnormality
in the bottle.
• a-contact (relay contact)
• Contact capacity: 250V AC, 1A (resistance load)
• Connection: M4 screw terminal block
Temperature/current output table
Temperature (℃) Output current (mA)
0 4
20 6
40 8
60 10
80 12
100 14
120 16
140 18
160 20
