Description and Function of Each Part
Main Unit
SN210/300/310/500/510
SQ500/510
SN200
Front/upper view
Packing
Cover
Droplet tray
Top board
Cover lock
Cover locking lever
Pressure gauge
Door
Drain level scale
Handle
Heat releasing outlet
Hook
Earth leakage breaker
Rating notice sticker
Intake of forced cooling fan
Water level observation
window for drain bottle
Drain bottle
Heat releasing outlet
Control panel
Rear view
External output terminal
(optional)
Power cord
Drain valve, Vapor cup,
and Vapor outlet
Caster
Heat releasing outlet
