39
Operation Method
External Output Terminal (optional)
Precautions
• Operate this product according to the procedure described in this Operation Manual. Failure to
follow the operation procedure described herein may result in a problem. The guarantee will
not apply if you operate the product in the wrong manner.
CAUTION!
• Turn off the breaker before connecting the cables.
• Connect a recorder or another appliance of 600 W or less in input impedance to the
temperature output terminal.
• Securely fasten all connections with the screws attached to the terminal block.
Connection procedure
• Connect the cables to the appropriate terminals.
• When using temperature output, use a shielded wire for the cable to be connected to prevent
noise.
ANALOG
＋ － COM NO
TIME UP
COM NO
ALARM
Connection terminal
