Form # 46290 Issue 09/05 97
OPTIONS AND ATTACHMENTS
REEL DRIVE SPROCKETS
A high torque reel drive sprocket (11 teeth) is standard on the 972 Combine Configuration Header (except
Australian units). The high torque is required for many conditions such as rice and other heavy crops. A high
speed reel drive sprocket (17 teeth) is standard on the 972 Windrower Configuration Header and Australian
Combine Headers. This is recommended when operating at speeds over 6 mph (10 km/h). Either sprocket is
available as an option to the factory installed sprocket. Two pitches of chain need to be added when
converting from high torque to high speed, and removed when converting high speed to high torque. See your
Dealer Parts Department to order sprockets.
CONDITIONED WINDROW SIDE DELIVERY SYSTEM
WholeGoods order number:
Deck and Mounting Parts – B4258
Forming Shield Package – B4287 (replaces existing
742 Hay Conditioner Forming Shields)
For side delivery of conditioned forage crops out the
right side of the windrower tractor. Allows forage
chopper to pick up two conditioned windrows at the
same time. A booklet containing Installation
Instructions, Operating Instructions and Parts Listings
is provided with the option package.
CONDITIONED WINDROW SIDE DELIVERY
SYSTEM
