Actuator Inspection
Series 215 Rotary Actuator Product Manual Maintenance 65
Actuator Rotor Dimensions
D IMENSION A
M ODEL M AXIMUM M INIMUM
IN . MM IN . MM
215.32, 215.35 1.5010 38.125 1.5007 38.118
215.41, 215.42 2.2511 57.178 2.2508 57.170
215.45 3.7512 95.280 3.7509 95.273
215.51 3.7512 95.280 3.7509 95.273
D IMENSION B
M ODEL M AXIMUM M INIMUM
IN . MM IN . MM
215.32,215.35,
215.41, 215.42
0.0010 0.025 0.0007 0.018
215.45,215.51 0.0012 0.03 0.0009 0.023
D IMENSION C
M ODEL N OMINAL
IN . MM
215.32 1.175 29.845
215.35, 215.41, 2.275 57.785
215.42 3.275 83.185
215.45 2.775 70.485
215.51 5.553 141.046
