MTS Series 215 Rotary Actuator User Manual
Page 44
Series 215 Rotary Actuator Product Manual
44
Test Setup Using No Flexures
Operation
Then:
B. Calculate the value of k
2
, the lateral stiffness of a solid cylindrical
specimen, by using the formula:
C. Substitute the calculated values for k
1
, k
2
, and the example values into
the original equation to compute the side load (P).
