Reaction Brackets
Introduction
Reaction Brackets
Reaction brackets provide a torsionally rigid connection between the torque cell
and the reaction base. Brackets provide some flexural capability and readily
accept MTS torque cells.
Reaction Bracket Dimensions and Ratings
M ODEL A B C D E F
IN . MM IN . MM IN . MM IN . MM IN . MM IN . MM
215.32 6.25 158.8 0.75 19 5.00 127 17.00 432 12.00 304.8 3.75 92.3
215.35 6.25 158.8 0.75 19 5.00 127 17.00 432 12.00 304.8 3.75 92.3
215.41 6.50 166.4 1.00 25 5.00 127 19.50 495 18.00 457.2 3.50 88.9
215.42 6.50 166.4 1.00 25 5.00 127 19.50 495 18.00 457.2 3.50 88.9
215.45 7.75 196.8 1.50 38 6.00 152 22.00 559 18.00 457.2 4.00 101.6
215.51 7.75 196.8 1.50 38 6.00 152 22.00 559 18.00 457.2 4.00 101.6
M ODEL G T HRUST L OAD *
H (M
AXIMUM )
T HRUST
D EFLECTION
I (M AXIMUM )
H ORIZONTAL
B ENDING
M OMENT *
J (M AXIMUM )
A NGULAR
D EFLECTION
K
V ERTICAL *
B ENDING
M OMENT L
(M AXIMUM )
A NGULAR
D EFLECTI
ON
M
IN . MM LBF N IN . MM LBF · IN
.
N· M RAD LBF · IN . N· M RAD
215.32 0.781 19.8 100 445 0.03 0.76 200 22 0.004 3500 395 0.003
215.35 0.781 19.8 100 445 0.03 0.76 200 22 0.004 3500 395 0.003
215.41 0.781 19.8 150 670 0.07 1.8 400 45 0.008 9000 1000 0.003
215.42 0.781 19.8 150 670 0.07 1.8 400 45 0.008 9000 1000 0.003
215.45 0.781 19.8 500 2200 0.06 1.5 2000 225 0.006 20,00
0 2260 0.0012
215.51 0.781 19.8 500 2200 0.06 1.5 2000 225 0.006 35,00
0 3960 0.0012
* Thrust load (H) and bending moments (J and L) are interdependent. H ratings assume J = 0 and L = 0.
J and L ratings assume H = 0. Ratings must be decreased in proportion to other loads present, for
example, if H = 75% of rating, J and L must not total 25% of rating.
Dimensions and ratings are subject to change without notice. Contact MTS for verification of dimensions
and ratings critical to your needs.
