Series 215 Rotary Actuator Product Manual 20
Options Specifications
Introduction
Foot Mounting Dimensions and Ratings
M ODEL A B C D
IN . MM IN . MM IN . MM IN . MM
215.32 6.25 158.8 0.75 19 5.00 127 17.00 432
215.35 6.25 158.8 0.75 19 5.00 127 17.00 432
215.41 6.50 166.4 1.00 25 5.00 127 19.50 495
215.42 6.50 166.4 1.00 25 5.00 127 19.50 495
215.45 7.75 196.8 1.50 38 6.00 152 22.00 559
215.51 7.75 196.8 1.50 38 6.00 152 22.00 559
M ODEL E F G T HRUST L OAD *
H (M AXIMUM )
IN . MM IN . MM IN . MM LBF N
215.32 12.00 304.8 3.75 92.3 0.781 19.8 100 445
215.35 12.00 304.8 3.75 92.3 0.781 19.8 100 445
215.41 18.00 457.2 3.50 88.9 0.781 19.8 150 670
215.42 18.00 457.2 3.50 88.9 0.781 19.8 150 670
215.45 18.00 457.2 4.00 101.6 0.781 19.8 500 2200
215.51 18.00 457.2 4.00 101.6 0.781 19.8 500 2200
M ODEL T HRUST
D EFLECTION
I (M AXIMUM )
H ORIZONTAL
B ENDING
M OMENT *
J (M AXIMUM )
A NGULAR
D EFLECTION
K
V ERTICAL * B ENDING
M OMENT L
(M AXIMUM )
A NGULAR
D EFLECTION
M
IN . MM LBF - IN . N- M RAD LBF - IN . N- M RAD
215.32 0.03 0.76 200 22 0.004 4500 508 0.003
215.35 0.03 0.76 200 22 0.004 4500 508 0.003
215.41 0.07 1.8 400 45 0.008 9000 1000 0.003
215.42 0.07 1.8 400 45 0.008 9000 1000 0.003
215.45 0.06 1.5 2000 225 0.006 20,000 2260 0.0008
215.51 0.06 1.5 2000 225 0.006 35,000 3960 0.0004
* Thrust load (H) and bending moments (J and L) are interdependent. H ratings assume J =
0 and L = 0. J and L ratings assume H = 0. Ratings must be decreased in proportion to other
loads present, for example, if H = 75% of rating, J and L must not total 25% of rating.
Dimensions and ratings are subject to change without notice. Contact MTS for verification of
critical dimensions and ratings.
