Kinze Grain Carts Rev. 4/14 - Manual (Page 99)

Upper Tank Side Panels and Bracing (1100/1300/1500)
ITEM PART NO. QTY. DESCRIPTION
1 GA16155 2 Corner Brace
2 GA16156 4 Panel Brace
3 G10071 116-148 Serrated Flange Nut, ½"-13
4 G10636 36 Carriage Bolt, ½"-13 x 1½"
5 GA16015 1 Front Upper Tank
6 G10014 80-112 Hex Head Cap Screw, ½"-13 x 1"
7 GD23297 4 Lower Cross Plate
8 GA16996 1 Flow Gate Indicator Support
9 GD23295 19-27 Cross Brace Strap
10 GD23296 4 Upper Cross Plate
11 GA16358
GA16012
GA16443 2
2
2 Upper Side (1100)
Upper Side (1300) (Shown)
Upper Side (1500)
12 GA15624 2 Window
13 GA16016 1 Rear Upper Tank
14 GA15638 2 Rear Side Brace
15 GD26682 5 Center Cross Plate
Grain Cart M0238-02
Rev. 4/13 P96
TM
