ITEM PART NO. QTY. DESCRIPTION
1 GD24063 2 Upper Screen Clamp Plate
2 G10004 4 Hex Head Cap Screw, ⅜"-16 x 1¼"
3 G10108 4 Lock Nut, ⅜"-16
4 GA16246 1 Stiffener Plate
5 G11415 48 Serrated Flange Nut, ⅝"-11
6 --- 1 See “Cross Brace Assemblies (2012 Production)” on page P83
See “Cross Brace Assemblies (2013 Production)” on page P84
7 GA16727
GA18757
GA17072 2
-
-
Tank Brace (1100/1300/1500)
Tank Brace (1100 Flotation/Track/Row Crop; 1500 Track)
Tank Brace (1100/1500) (2012 Production)
9 GA17061
GA17062
GA18755 1
-
-
Wheel Well Truss (Flotation/Row Crop)
Wheel Well Truss (Track) (2012 Production)
Wheel Well Truss (Track) (2013 Production and On)
10 --- 1 See “Cross Brace Assemblies (2012 Production)” on page P83
See “Cross Brace Assemblies (2013 Production)” on page P84
11 G10005 32 Hex Head Cap Screw, ⅝"-11 x 1¾"
12 G10305
G11091 112
112 Carriage Bolt, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
13 GA16710 6 Side Stake
14 G10039 60 Hex Head Cap Screw, ½"-13 x 1¾"
15 G11389 120 Flat Washer, ½" Plated SAE
16 G10111 60 Lock Nut, ½"-13
17 GA16278 1 Front Side Stake, R.H.
GA16709 1 Front Side Stake, L.H. (Shown)
18 G10112 6 Lock Nut, ¾"-10
19 G11392 12 Flat Washer, ¾" SAE
20 G10027 6 Hex Head Cap Screw, ¾"-10 x 2½"
21 G10636
G10111 16
16 Carriage Bolt, ½"-13 x 1½"
Lock Nut, ½"-13
Lower Tank Supports (1100/1300/1500)
Grain Cart M0238-02
Rev. 4/13 P82
